HN120

PowerLite® High Pressure
Concrete Pinner up to 2-1/2"

At only 6.4 lbs., the safety equipped and lightweight Powerlite® HN120 concrete pinner is lighter than most competitor’s tools without sacrificing driving power. Unlike powder actuated tools, this tool is faster, more efficient and doesn’t require a license or powder loads to operate. Backed by the power of a 500 PSI Powerlite® compressor the HN120 can easily drive pins, through a multitude of materials including metal, steel, concrete and wood, with minimal recoil. MAX is committed to manufacturing reliable tools that have been designed to deliver enhanced performance while making sure that users can carry out safe operations.

1 Year Warranty

Applications

  • Metal track to concrete
  • Metal track to steel
  • Wood to concrete
  • Wood to steel I beam

Features

  • SAFER THAN CONVENTIONAL CONCRETE PINNERS
    The HN120 is a faster, safer and a more cost effective alternative to powder actuated tools, and doesn’t require a license to operate.
  • WIDE RANGE OF FASTENERS AVAILABLE
    The MAX HN120 can shoot a variety of fasteners into wood, steel, or concrete including the AccuEmbed .157" Pins. LEARN MORE ABOUT POWERLITE FASTENER
  • VERY POWERFUL
    Drives .307" head pins into concrete or steel with 2,231 inch lbs. driving force.
  • LIGHTWEIGHT WITH LESS RECOIL
    At at only 6.4lbs, this lightweight tool has less recoil than P.A.T tools.
  • LESS MAINTENANCE TOOL
    The patented, self-cleaning maintenance free end cap filter captures foreign substances before they can enter the tool and automatically ejects them when the air hose is disconnected.
  • SELF-CLEANING FILTER FOR RELIABLE OPERATIONS
    The patented, self-cleaning maintenance free end cap filter captures foreign substances before they can enter the tool and automatically ejects them when the air hose is disconnected.
  • LARGE CAPACITY MAGAZINE
    The HN120 holds 50 pins and saves reloading time and operating cost.

Specifications

WEIGHT
6.4 lbs
DIMENSIONS

15 3/4"(H) x 3 3/8"(W) x 12 3/8"(L)

MINIMUM OPERATION PRESSURE
210 PSI
MAXIMUM OPERATION PRESSURE
320 psi
AIR INLET SIZE
7/16"
MAGAZINE CAPACITY
50
DEPTH CONTROL
No
JAM CLEARING
No

TRIGGER TYPE

Sequential Fire Trigger

AIR CONSUMPTION
(FT3/CYCLE)
0.166
ACCESSORIES
Safety glasses, Nose attachments, Carry case

Fasteners

VISIT OUR POWERLITE FASTENER WEB PAGE FOR MORE DETAILS

Application (lower) Application (Upper) Item# Length Shank Dia. Pins/ Coil Case Qty. Test report
Concrete Exterior Metal Track CP-C821X0SP-ICC 3/4"+.079" .157" 50 1000 ESR-4320
Concrete Exterior Metal Track CP-C828X0SP-ICC 1"+.079" .157" 50 1000 ESR-4320
Concrete Exterior Metal Track CP-C834X0SP-ICC 1-1/4"+.079" .157" 50 1000 ESR-4320
Concrete Exterior Metal Track CP-C840X0SP-ICC 1-1/2"+.079" .157" 50 1000 ESR-4320
Concrete Metal Track CP-C819W7-ICC 3/4" .145" 50 1000 ESR-4320
Concrete Metal Track CP-C825W7-ICC 1" .145" 50 1000 ESR-4320
Concrete Metal Track CP-C832W7-ICC 1-1/4" .145" 50 1000 ESR-2024
Concrete Wood (1/2”) CP-C832W7-ICC 1-1/4" .145" 50 1000 ESR-2024
Concrete Wood (3/4”) CP-C838W7-ICC 1-1/2" .145" 50 1000 ESR-2024
Concrete Wood (1”) CP-C851W7-ICC 2" .145" 50 1000 ESR-4320
Concrete Wood (1-1/2”) CP-C864W7-ICC 2-1/2" .145" 50 1000 ESR-4320
Concrete Subfloor/Fiber cement siding (1/2") CP-C832W7-SF (w/o washer) 1-1/4" .140" 50 1000
Concrete Subfloor/Fiber cement siding (3/4") CP-C838W7-SF (w/o washer) 1-1/2" .140" 50 1000
I-beam (3/16"-1/4") Wood (1/2”) CP-W823W4SP 7/8" .133"/.113" 50 2000 Yes
I-beam (3/16"-1/4") Wood (3/4”) CP-W833W4SP 1-1/4" .133"/.113" 50 2000 Yes
I-beam (3/16"-3/8") Wood (1”) CP-W838W4SP 1-1/2" .133"/.113" 50 2000 Yes
I-beam (3/16"-3/8") Wood (1-1/2”) CP-W850W4SP 2" .133"/.113" 50 2000 Yes
I-beam (1/4"-1/2") Metal track or Clip CP-W814W4SP-AL (Top Hat) 9/16" .133"/.113" 50 2000 Yes
I-beam (1/4"-1/2") Metal track or Clip CP-W816W4SP-AL (Top Hat) 5/8" .133"/.113" 50 2000 Yes
I-beam (1/4"-1/2") Metal track or Clip CP-W820W4SP-AL (Top Hat) 13/16" .133"/.113" 50 2000 Yes
I-beam (3/16"-1/4") Metal track or Clip CP-W823W4SP-AL (Top Hat) 7/8" .133"/.113" 50 2000 Yes
Steel (18-12Ga.) Plywood/Exteria drywall (1/2”) CAP32W4-H 1-1/4" .133" Knurl 50 2000 Yes
Steel (18-12Ga.) Plywood/Exteria drywall (3/4”or1") CAP38W4-H 1-1/2" .133" Knurl 50 2000 Yes
Steel (18-12Ga.) Wood (1-1/2”) CAP50W4-H 2" .133" Knurl 50 2000 Yes
Steel (18-12Ga.) Wood (1-1/2”) CAP65W4-H 2-1/2" .133" Knurl 50 2000 Yes
