CN445R3

Roofing Coil Nailer up to 1-3/4"

Engineered by the manufacturer of the world’s first roofing nailer, MAX combines durability and performance in the safety equipped SuperRoofer®CN445R3. Equipped with a full round head driver blade allows operators to drive nails in flush for dependable holding power. To ensure the durability of the CN445R3, the tar resistant nose is designed to block tar build up to 8x longer than conventional tools. The patented self-cleaning end cap filter, traps foreign substances before they can enter the tool and safely ejects them when the air hose is disconnected. MAX is committed to manufacturing reliable tools that have been designed to deliver enhanced performance while making sure that users can carry out safe operations.

1 Year Warranty

Applications

  • Asphalt and fiberglass shingles
  • Vinyl siding
  • Lath wire to plywood
  • Wooden box assembly

Features

  • REDUCED TAR BUILD UP
    Tar resistant nose is designed to resist tar 8x longer than conventional tools. When necessary, the SuperRoofer®’s contact foot is easy to remove, clean and is also inexpensive to replace.
  • SELF-CLEANING FILTER FOR RELIABLE OPERATIONS
    The patented, self-cleaning maintenance free end cap filter, captures foreign substances before they can enter the tool and automatically safely ejects them when the air hose is disconnected.
  • SIMPLE TOOL MAINTENANCE
    A removable contact foot allows roofers to safely maintain and clean components of the tool without having to submerge the tool in corrosive cleaning agents.
  • NO NAIL WASTE OR JAMS
    A nose magnet holds the last nail in place, allowing contractors to use every nail in the coil; it also prevents the tool from jamming.
  • CONSISTENTLY AND ACCURATELY SHOOTS NAILS
    The depth adjustment dial allows operators to effortlessly drive nails into hard materials, and also control depth of drive when fastening soft materials, for a consistently polished finish.
  • AVOID TRIP HAZARDS
    A tangle free swivel fitting prevents tangling of the hose while keeping roofers safe from potential fall hazards.
  • EXTREME DRIVING POWER
    Full round head driver blade for better holding power.

Specifications

WEIGHT
5.6 lbs
DIMENSIONS

10 1/2"(H) x 4 1/2"(W) x 12 3/16"(L)

MINIMUM OPERATION PRESSURE
70 PSI
MAXIMUM OPERATION PRESSURE
120 PSI
AIR INLET SIZE
1/4"
MAGAZINE CAPACITY
120
DEPTH CONTROL
Yes
JAM CLEARING
No

TRIGGER TYPE

Rapid Fire Trigger

AIR CONSUMPTION
(FT3/CYCLE)
0.047
ACCESSORIES
Safety glasses

Fasteners

COLLATION TYPE
Wire
NAIL GUN ANGLE

15

STRIP OR COIL
Coil
COMPATIBLE FASTENER TYPES
Roofing coil nails
MINIMUM FASTENER SIZE
3/4"
MAXIMUM FASTENER SIZE
1-3/4"
MAXIMUM NAIL DIAMETER
.120"

Manuals

Owner's Manual

Download

Documents

Parts List

Download

Brochure

Download
